| Interface | 24 RJ45 Ports + 8 SFP+ Ports + 1 MGMT Port + 1 Console Port + 1 USB Port | | Port Speed | 24 RJ45 Ports 10/100/1000Mbps + 8 SFP+ Ports 1/10GE |
| Switching Capacity | 880Gbps |
| Forwarding Rate | 512Mbps |
| MAC Table | 64K |
| ARP Table | 24K |
| Routing Table | 24K IPv4 + 14K IPv6 (unicast) 4K IPv4 + 2K IPv6 (multicast) |
| VLAN | Up to 4096 802.1Q / Port Based / Private VLAN / GVRP / Super VLAN |
| Redundancy Control | STP / RSTP / MSTP / LACP / RLDP / ERPS / |
| Management Protocol | Web / Cloud / APP / SNMP / CLI / RMON |
| DHCP | Server / Client / Snooping / Relay / IPv6 Snooping / IPv6 Client / IPv6 Relay |
| Routing | IPv4/IPv6 static routing / RIP / RIPng / OSPFv2 / OSPFv3 / BGP4 and BGP4+ / IS-ISv4 and IS-ISv6 |
| ACL | Standard ACL / Extended ACLs / MAC Based ACL / Time Based ACL / IPv6 ACL |
| QoS | 8 Priorities per Port: RR / SP / WRR / DRR / WFQ / SP+WRR / SP+DRR / SP+WFQ |
| QinQ | Basic QinQ / Flexible QinQ |
| Multicast | IGMP v1, v2, v3 / IGMP Proxy / IGMP v1, v2, v3 Snooping / IGMP Filtering / IGMP Fast-leave / PIM-DM / PIM-SM / PIM-SSM / MLD Snooping v1,v2 / MLD v1,v2 / PIM-SMv6 and PIM-SSM v6 |
| Security | AAA / RADIUS / TACAS+ / 802.1x / SSH / IP Source Guard / CPP and NFPP / Port Protection |
| Virtual Stacking & High Availability | VSU Technology / ERPS / REUP |
| Operating Temperature | 0° C - 45° C |
| Power Consumption | <60 W (excluding expansion modules) / <85 W (including expansion modules) |
| Power Supply | Not included, 2 Slots support 1+1 Redundancy Hot Swappable. Requires a minimum of 1 RG-PA150IB-F Unit |
| Dimensions | 440 x 340 x 44 mm |
